Technical Sheet
dodom.com
Features
| Dimensions and format | |
|---|---|
| Overlap width | 100 mm (3.94 in) |
| Weld width | 18 mm x 2 (0.71 in x 2) |
| Inner cavity | 16 mm (0.63 in) |
| Product dimensions | 46 x 32 x 45 cm (18.11 x 12.60 x 17.72 in) |
| Gross weight | 20 kg (44.09 lb) |
| Net weight | 13 kg (28.66 lb) |
| Strength and performance | |
| Seam strength | ≥85% of base material |
| Electrical system and motor | |
| Voltage | 220V |
| Frequency | 50/60Hz |
| Power | 1800W |
| Heating temperature | 0 ~ 450°C (32 ~ 842°F) |
| Welding speed | 0.5 ~ 5 m/min (1.64 ~ 16.4 ft/min) |
| Compatibility and use | |
| Material thickness to weld | 0.8 mm ~ 4.0 mm (0.031 in ~ 0.157 in) |
Packaging dimensions
| Machine: Width | 46 cm (18.11 in) |
|---|---|
| Machine: Height | 32 cm (12.6 in) |
| Machine: Depth | 45 cm (17.72 in) |
| Machine: Weight | 20.0 kg |
Warranty
Official KORWINS® warranty
What's covered
- Extended Dodom warranty of 18 months from delivery, which extends the protection of Law 358-05 (Arts. 66–70), against manufacturing defects in the Hot wedge welding machine.
- Confirmed defect: replacement or refund of the amount paid.
What's not covered
- Any damage or deterioration unrelated to the manufacturing of the Hot wedge welding machine, such as damage resulting from use, normal wear and tear, or external causes, including force majeure.
Warranty valid only on genuine KORWINS product, a brand distributed exclusively by Dodom. Reproducing this datasheet does not transfer any manufacturer warranty or backing.
